HP Z34c G3 User Manual

14
PICTURE 2
.
PICTURE 3
S3
1) Unlock 2 screws and disassemble USB BD from the MF as the picture 1.
2) Tear off the conduct sponge from the MF as the picture 2.
3) Tear off 4 acetate tapes from Panel as the picture 3.
4) Tear off the acetate tape from the camera wire as the picture 4.
5) Unlock 20 screws from the MF as the picture 3.
6) Unlock 6 screws and disassemble the camera from the MF as the picture 4.
PICTURE 1 PICTURE 2

HP Z34c G3 Specifications

General

Panel type	VA
Pixel pitch	0.2325 x 0.2325 mm
Aspect ratio	21:9
Response time	8 ms
Display surface	Matt
Display diagonal	34 \
Display technology	LED
Vertical scan range	59 - 61 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	88 - 90 kHz
Screen curvature rating	1900R
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	720 x 400, 1600 x 900, 2560 x 1440, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1366 x 768, 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
HDCP	Yes
DisplayPort version	1.4
USB upstream port type	USB Type-B
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Power consumption (max)	250 W
Power consumption (standby)	0.5 W
Power consumption (typical)	60 W
Package depth	226 mm
Package width	952 mm
Package height	504 mm
Package weight	16600 g
Tilt angle range	-5 - 10 °
Panel mounting interface	100 x 100 mm
Product color	Black, Silver
Market positioning	Business
Megapixel	5 MP
RMS rated power	5 W
Number of speakers	2
Sustainability certificates	EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth (with stand)	272.5 mm
Width (with stand)	813.8 mm
Height (with stand)	585.2 mm
Weight (with stand)	- g
Depth (without stand)	105 mm
Height (without stand)	389.2 mm
Weight (without stand)	11100 g
