HP Z6 G4 User Manual

8 Using HP PC Hardware Diagnostics (UEFI)
HP PC Hardware Diagnostics is a Unied Extensible Firmware Interface (UEFI) that allows you to run diagnostic
tests to determine whether the computer hardware is functioning properly. The tool runs outside the
operating system so that it can isolate hardware failures from issues that are caused by the operating system
or other software components.
When HP PC Hardware Diagnostics (UEFI) detects a failure that requires hardware replacement, a 24-digit
Failure ID code is generated. This ID code can then be provided to support to help determine how to correct
the problem.
NOTE: To start diagnostics on a convertible computer, your computer must be in notebook mode and you
must use the keyboard attached.
To start HP PC Hardware Diagnostics (UEFI), follow these steps:
1. Turn on or restart the computer, and quickly press esc.
2. Press f2.
The BIOS searches three places for the diagnostic tools, in the following order:
a. Connected USB drive
NOTE: To download the HP PC Hardware Diagnostics (UEFI) tool to a USB drive, see Downloading
HP PC Hardware Diagnostics (UEFI) to a USB device on page 37.
b. Hard drive
c. BIOS
3. When the diagnostic tool opens, select the type of diagnostic test you want to run, and then follow the
on-screen instructions.
NOTE: If you need to stop a diagnostic test, press esc.
36 Chapter 8 Using HP PC Hardware Diagnostics (UEFI)

HP Z6 G4 Specifications

General

Tcase	76 °C
Stepping	M0
Processor cache	16.5 MB
Processor cores	12
Processor model	4116
System bus rate	- GT/s
Processor socket	LGA 3647 (Socket P)
Processor threads	24
Processor codename	Skylake
Processor frequency	2.1 GHz
Processor cache type	L3
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Maximum number of PCI Express lanes	48
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2400 MHz
Maximum internal memory supported by processor	768 GB
On-board graphics card model	-
Memory slots	12x DIMM
Internal memory	16 GB
Memory channels	Hexa-channel
Memory clock speed	2666 MHz
Maximum internal memory	384 GB
Memory layout (slots x size)	2 x 8 GB
Wi-Fi	No
Ethernet LAN data rates	10, 100, 1000 Mbit/s
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Optical drive type	DVD Super Multi
Total storage capacity	512 GB
Power supply	1000 W
PS/2 ports quantity	2
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	10
Product color	Black
Country of origin	China
Product type	Workstation
Scalability	2S
Processor code	SR3HQ
Processor ARK ID	120481
Intel TSX-NI version	1.00
Processor package size	76.0 x 56.5 mm
Supported instruction sets	AVX, AVX 2.0, AVX-512, SSE4.2

Weight and Dimensions

Depth	465 mm
Width	169 mm
Height	445 mm
Weight	13100 g
