Huawei AP5030DN Product Description

Huawei AP5030DN Access Points
Product Description
4 Technical Specifications
Issue 01 (2014-04-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
16
Item
Description
Operating humidity
5% to 95% (non-condensing)
Waterproof grade
IP41
Atmospheric
pressure
70 kPa to 106 kPa
4.2 Radio Specifications
Table 4-2 Radio specifications
Item
Description
Antenna
type
Built-in antenna
Antenna
gain

2.4G: 4dBi

5G: 5dBi
Maximum
number of
concurrent
users

Fit AP mode: ≤ 256

Fat AP mode: ≤ 64
Maximum
transmit
power for
each radio

2.4 GHz: 20 dBm

5 GHz: 17 dBm
NOTE
The 2.4 GHz radio does not support the 40M bandwidth in FCC regions (including
America).
The actual transmit power depends on local laws and regulations.
You can adjust the transmit power from the maximum transmit power to 1 dBm, with
a step of 1 dB.
Maximum
number of
non-overlap
ping
channels
2.4 GHz
802.11b/g

20 MHz: 3
802.11n

20 MHz: 3

40 MHz: 1
5 GHz

802.11a
− 20 MHz:
5

802.11n
− 20 MHz:
5
− 40 MHz:
2

802.11ac
− 20MHz: 5
− 40MHz: 2
− 80MHz: 1
NOTE
The table uses the number of
non-overlapping channels supported by
China as an example. The number of
non-overlapping channels varies in
different countries. For details, see the
Country Code & Channels compliance
status
NOTICE
If the AP is delivered to the USA, pay
attention to the following on channel
and frequency band usage.
1.
The country code of the AP is fixed.
2.
The frequency band ranging from
5.15 GHz to 5.25 GHz can only be
used indoors.
3.
High power radars working at
