20
Parameter Setting
Password used for logging in to the Web-based
configuration utility
admin
DHCP server function Enable
Wireless network function Enable
7.4
Technical Specifications
Item Specification
Entire-device power supply 5 V DC, 1 A
Entire-device power consumption < 5 W
Ambient temperature for operation
0°C to 40°C (32℉ to 104℉)
Relative humidity for operation 5% to 95%, non-condensing
Dimensions (L × W × H) 118.4mm × 40.4mm × 90.3mm
Weight About 115 g
ADSL standards z ITU G.992.1 (G.dmt) Annex A
z ITU G.994.1 (G.hs)
z ANSI T1.413 Issue 2
ADSL2 standard ITU G.992.3 (G.dmt.bis) Annex A
ADSL2+
standard
ITU G.992.5 Annex A
Standards
WLAN standard 802.11b , 802.11g and 802.11n (2.4GHz)
G.dmt
T1.413
z Maximum downlink rate: 8 Mbit/s
z Maximum uplink rate: 896 kbit/s
DSL
transmission
rates
G.992.5
(ADSL2+)
z Maximum downlink rate: 24 Mbit/s
z Maximum uplink rate: 1024 kbit/s
