25
5.3 Connecting to the Internet When
Using USB Mobile Broadband
The HG630b is not set to automatically connect through a supported
3G USB mobile broadband T-Stick when it is inserted. A mobile
broadband connection must be manually started by the user.
To connect, do as follows:
Step 1
Log in to the web-based configuration utility.
Step 2
Click Advanced > PIN in the navigation tree on the left to
display the PIN Page.
Step 3
Enable the UPLINK function.
1. Choose the UPLINK page.
2. Select the HSPA Backup check box.
3. Click Submit.
Step 4
Verify the PIN code of your SIM card.
1. Choose the PIN page.
2. Select Verify from the PIN operation drop-down combo
box.
3. Enter the PIN code that provided by your SIM card
operator in the PIN text box.
4. Click Submit.
Step 5
Set the working mode of the HG630b to PPP.
1. In the navigation tree on the left of the web-based
configuration utility, choose Basic > WAN.
2. Click New.
Y
