Huawei OceanStor S5500T User Manual

Checking installation tools
1c
Checking components
Checking circuit breakers
1b 1a
1 Installation Preparations
The following installation tools are required:
 Phillips screwdriver (M3 to M6)
 Flat-head screwdriver (M3 to M6)
 Diagonal pliers
 Floating nut mounting bar
To protect devices connected to the storage system from
unexpected power-off caused by a power failure, the
current of the AC power circuit breaker is 16 A.
3
NOTE
 Data switches are optional for controller expansion. All contents involving data switches are optional.
 2 U controller enclosures support two types of disks, 12-slot 3.5-inch disks and 24-slot 2.5-inch disks.
 The Packing List contains all materials required by the installation. The bag containing the Packing List
is attached to the outside of the carton.
mini SAS HD cable
Adjustable
guide rails
Floating nut
and M6 screw
Multi-mode optical
fiber cable
Mini SAS cable
Network cable
Installation template
(for 2 U devices)
Ground cable
Installation template
(for 4 U devices)
Disk enclosure (4 U)
Controller enclosure (2 U)
File engine (4 U)
Cable manager
Mini SAS HD to
mini SAS cable
High-density disk enclosure (4 U)
Bearing guide rails
Disk enclosure (2 U)
Data switch (1 U)
Front panel of a 2 U
controller enclosure
Front panel of a 4 U
disk enclosure
AOC cable
