Huawei OptiXstar EG8145X6 User Manual

4 Technical Specications
Product Function
EG8145X6 ● 4 Ethernet ports
● 1 POTS port
● 1 USB port
● 2.4 GHz & 5 GHz Wi-Fi 6
● Power adapter input: See the nameplate on the adapter.
● System power supply: See the nameplate on the device.
● Ambient temperature: 0ºC to +40ºC
● Ambient humidity: 5%–95% (non-condensing)
● Dimensions (H x W x D): 35 mm x 195 mm x 125 mm
● Weight: About 400 g
● Maximum system power consumption: 18 W
Huawei OptiXstar EG8145X6
Quick Start for QR code 4 Technical Specications
Issue 01 (2020-07-01) Copyright © Huawei Technologies Co., Ltd. 8

Huawei OptiXstar EG8145X6 Specifications

General

Power Supply	12 V DC, 1.5 A
Ethernet Ports	4 x 10/100/1000 Mbps
PON Interface	GPON
USB Ports	1 x USB 2.0
Frequency Bands	2.4 GHz, 5 GHz
Antennas	4
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to +70°C
Operating Humidity	5% to 95% (non-condensing)
Downstream Rate	2.5 Gbps
Upstream Rate	1.25 Gbps
