No. Indicator Identifier Status Description
Orange The system is
performing self-
check during startup.
Blinking green The system is
operating properly.
Red After registering, the
system does not
operate properly, or a
power alarm, fan
alarm, or temperature
alarm is generated.
4 Mode
indicator
MODE Off The service interface
indicator is in the
default mode
(STAT).
Green The service interface
indicator indicates the
interface speed. After
45 seconds, the
service interface
indicator
automatically restores
to off.
Red
The service interface
indicator indicates the
stack ID. After 45
seconds, the service
interface indicator
automatically restores
to off.
As shown in Figure 2-4, the button marked "5" is the mode switching button. When you press
the mode switching button once, the mode indicator turns green and the related interface indicator
enters the speed state. When you press the mode switching button for a second time, the mode
indicator turns red and the related interface indicator represents the stack status. When you press
the mode switching button for a third time, the mode indicator restores to the default state (off).
If you do not press the mode switching button within 45 seconds, the mode indicator
automatically restores to off. The following table describes the meanings of indicators.
Table 2-5 Description of indicators in different modes
Display Mode
Status Description
STAT Off The interface is not connected or
has been shut down.
S3700&S5700&S6700 Series Ethernet Switches
Quick Start 2 Product Hardware Introduction
Issue 02 (2012-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
12
