3.1.2 Wi-Fi

IEEE 802.11b/g/n/ax (up to 574Mbit/s over a 2.4 GHz Wi-Fi network)

IEEE 802.11a/n/ac/ax (up to 2402Mbit/s over a 5 GHz Wi-Fi network)

Simultaneous dual-band (11ax 2.4GHz 574Mbit/s and 11ax 5GHz 2402Mbit/s) with a
maximum wireless transmission rate of 2976 Mbit/s.
NOTE
The data rates shown are theoretical in nature. Actual data rates may vary depending on operating
environment, wireless device, and other factors. Data rate comparisons (if any) are for the purpose of
scientific explanation, and should be used for reference only.

Adopts Huawei's unique internal 2.4 GHz and 5 GHz antennas for better WiFi coverage.

Supports IEEE 802.11ax wireless 2.4 GHz 2x2 MIMO and IEEE 802.11ax wireless 5
GHz 2x2.

Supports simultaneous Wi-Fi access on the 2.4 GHz and 5 GHz bands, and supports up
to 250+ devices on dual bands.

Advanced Encryption Standard (AES) and Temporal Key Integrity Protocol (TKIP) are
supported.

Supports WPA/WPA2-PSK and WPA2-PSK/WPA3-SAE.

Supports dual-band auto-selection: The 2.4 GHz and 5 GHz Wi-Fi names are the same.
You will automatically connect to the faster Wi-Fi network.

Supported 5 GHz channels: channels 36-64 and 100-140 in countries and areas
using the CE standards, and channels 36-64, 100-140 and 149-165 in countries
and areas using the FCC standards.
NOTE
 Channel values vary with countries.
 Relationship between 5 GHz channels and frequency bands: Channels 36-48 correspond
to band 1 (5.15-5.25 GHz). Channels 52-64 correspond to band 2 (5.25-5.35 GHz) DFS.
Channels 100-140 corresponds to band 3 (5.47-5.725 GHz) DFS. Channels 149-165
correspond to band 4 (5.725-5.85 GHz).
3.2 Port
10/100/1000 Mbit/s WAN/LAN auto-adaptation Ethernet port: 3
3.3 Power Supply Specification

Power supply: 12V DC, 1 A

Power consumption: < 12W

Input voltage: 100 - 240V AC

Input voltage frequency: 50 – 60 Hz

Huawei WiFi Mesh 3 Specifications

General

Antenna type	Internal
Product type	Mesh system
Product color	White
LED indicators	Yes
Maximum coverage	600 m²
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Flash memory	128 MB
Internal memory	256 MB
Number of products included	3 pc(s)
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Security algorithms	WPA3
Networking standards	IEEE 802.11k, IEEE 802.11r, IEEE 802.11v
WLAN data transfer rate (first band)	574 Mbit/s
WLAN data transfer rate (second band)	2402 Mbit/s
Ethernet LAN (RJ-45) ports	3
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (typical)	12 W

Weight and Dimensions

Depth	107 mm
Width	70 mm
Height	174 mm
Weight	413 g
