Huawei WS322 User Manual

8 Maintenance Guide
WS322 300Mbps Wireless Range Extender
User Guide
8-4
Step 1 Press the WS322 On/Off button to power the WS322 on.
Step 2 Press and hold the Reset button for 6 seconds or more.
The WS322 will restart, which will cause temporary network
interruptions.
After the WS322 is restored to its default settings, change the computer IP
address so that it is in the same network segment as the 192.168.33.1 default IP
address.

Huawei WS322 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Rack mounting	No
Bandwidth (first)	2.4 GHz
Ethernet LAN (RJ-45) ports	1
DHCP client	-
Antennas quantity	2
Security algorithms	128-bit WEP, 64-bit WEP, TKIP, WEP, WPA-PSK, WPA2-PSK, WPS
Certification	CCC, CE, FCC, RoHS
AC input voltage	100 - 240 V
Power consumption (typical)	5 W
Storage temperature (T-T)	5 - 95 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	30.7 mm
Width	73 mm
Weight	200 g
