Huawei WS322 User Manual

WS322 300Mbps Wireless Range Extender
User Guide
8 Maintenance Guide
8-3
8.3 Restoring Default Settings
Using the Configuration Tool
If the WS322 parameter settings were configured incorrectly, log in to the web
management page to reload the default configuration file and restore the WS322 to
its default settings. Perform this operation with caution. After the WS322 is restored
to its default settings, all custom data and settings will be lost, and the password will
be restored to admin.
Step 1 Log in to the web management page.
Step 2 Click Advance Settings.
Step 3 In the navigation tree, choose Maintenance > Device.
Step 4 Click Reset.
Step 5 Click Restore Default Settings.
Step 6 In the displayed dialog box, click OK.
Using the Reset Button
If you forget the login password to the web management page or could not access the
web management page, use the Reset button on the WS322 rear panel to restore the
WS322 to its default settings. Perform this operation with caution. After the WS322
is restored to its default settings, all custom data and settings will be lost, and the
password will be restored to admin.

Huawei WS322 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Rack mounting	No
Bandwidth (first)	2.4 GHz
Ethernet LAN (RJ-45) ports	1
DHCP client	-
Antennas quantity	2
Security algorithms	128-bit WEP, 64-bit WEP, TKIP, WEP, WPA-PSK, WPA2-PSK, WPS
Certification	CCC, CE, FCC, RoHS
AC input voltage	100 - 240 V
Power consumption (typical)	5 W
Storage temperature (T-T)	5 - 95 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	30.7 mm
Width	73 mm
Weight	200 g
