19
Specifi cations
5.4 Waveform Outputs (MD2 Only)
Analogue Zero crosser, 3.5V full scale per channel (forward and
reverse). Conversion factor automatically adjusted to give
full scale outputs at ±0.1% (±10%) of probe frequency (e.g.
±8kHz for VP8)
Digital Data formatted to interface with Printa II or Recorder
software running on compatible computer. Conversion
factors automatically set as per analogue outputs.
CAL Function Automatic sequence of CAL levels set to ±0.05% (±10%)
and ±0.1% (±10%) of probe frequency (e.g. ±4kHz & ±8kHz
for VP8) with zero baseline at start and end of sequence.
5.5 General
Max. Audio Output
(Loudspeaker)
500mW rms typical
Auto shut-off 3 minute no signal
10 minute unconditional
Headphones
Max. output Power: 25 mW rms (32Ω)
Connector: 3.5mm stereo jack socket
Max. applied voltage: +9Vdc
RS232 Interface
(MD2 only)
Data format: RS232C
Connector: 8pin subminiature DIN socket
Max. applied voltage: +5Vdc
Battery Type IEC 6LR61 or IEC 6LP3146
Battery Life Typically, 250 x 1 minute examinations
Size Height 5.5”, Depth 1.1”, Width 2.9”
Weight 10oz including probe and battery
5.6 Environmental
Operating Storage
+50°F to +86°F
(+10°C to +30°C)
Temperature range +14°F to +104°F
(-10°C to +40°C)
10% to 90% (non
condensing)
Relative Humidity 93% maximum
860mb to 1060mb Pressure 860mb to 1060mb
