Unpacking
1. Remove unit from carton and
discard all packaging. NOTE: Save all
parts bags
Assemble Hose
1. Slide the quick connector towards
the compressor body and insert the
hose to the quick connector.
Release quick connector.
Assemble Accessories
The unit is supplied with an
accessory kit and inflator/deflator kit,
choose the accessory needed.
Assemble Accessory Kit
To Assemble Female Tire Chuck
1. Assemble female tire chuck (a) to
hose (b) and tighten securely with
wrenches.
To Assemble Accessories
1. Attach the blow gun (c) to hose (b)
Risk of unsafe operation. If an
accessory is not being used
with the blow gun, the safety
nozzle MUST be assembled
2.
Assemble the safety nozzle (d),
rubber blow gun tip (h), or blow gun
adapter (e) to blow gun. NOTE: To
use the inflating needle (f) or the
tapered inflator(g), need to use the
blow gun adapter(e) to assembled
to the blow gun
3. Attach the inflation needle(f) to
the blow gun adapter on the
blower gun.
Assemble Inflator/Deflator Kit
The blow gun (c) and blow gun adapter
(e) from the accessory kit is needed to
use the inflator/deflator kit.
1. Attach the blow gun to hose.
2. Attach blow gun adapter to blow
gun.
3. Attach the inflation needle (f),
tapered nozzle (g), or high flow
inflator/deflator body (i) to the
blow gun adapter on the blow
gun.
4. If using the inflator/deflator
choose the nozzle needed and
see the "How to use High Flow
Inflator/Deflator Adapter Body"
instructions in the Operation
section for the correct procedure.
9
c
e
f
i
g
Safety Nozzle
