8
SPECIFICATIONS
Running horsepower
1.7 HP
Air tank capacity
33 gal.
Air pressure
165 PSI max.
Air delivery
6.8 SCFM at 40 PSI
5.1 SCFM at 90 PSI
Tank Fill-up Time
8 minutes
Lubrication
Oil free
Input
120V, 60 Hz, Single phase
AC only, 15 Amps.
Minimum branch circuit requirement
15 A
Fuse type
Time delay
Net weight
110 lbs.
DUTY CYCLE
This air compressor pump is capable of running continuously. However, to prolong the life of your air compressor,
it is recommended that a 50% average duty cycle be maintained; that is, the air compressor pump should not run
more than 30 minutes in any given hour.
Pre-Operation
Part Description Quantity
A Air Compressor Unit (fully assembled)
1
A
