Husqvarna 150BT User Manual

English
16
 HARNESS
NOTE
The harness must always be worn when working with the machine. Failure to do
so means you will be unable to maneuver safely and this can result in injury to
yourself or others.
A correctly adjusted harness and machine significantly facilitates the work. Adjust the
harness to give the best working position.
Tighten the side straps so that the pressure is evenly distributed across the shoulders.
 WAIST BELT [150BT] [170BT] [180BT]
• The waist belt is attached to the rings on the left and right sides of the frame.
NOTE
130BT has no waist belt.
Place the waist belt over your waist and not too far down on the stomach. Tighten the
waist belt strap so that you feel the weight of the blower resting on your hip.
• Be sure to always tighten the buckle in front of your body.
WARNING
• If you are not using a waist belt, be sure to remove it from the unit and store it.
• There is a risk that the belt will be caught, toppling the unit.
• There is a danger that the belt will be sucked into the fan.
F8
F9
F10
F11
F12
Assembly
130BT&180BTEU‑65.fmPage16Friday,December7,20074:00PM

Husqvarna 150BT Specifications

General

Engine Displacement	50.2 cc
Fuel Tank Volume	42.27 fl oz
Engine Type	2-stroke
Sound Power Level	104 dB(A)
Maximum Air Volume	434.37 cfm
Dry Weight	4.7 kg
Maximum Air Speed	75 m/s
