MAINTENANCE
36 – English
Adjustment of the oil pump
The oil pump is adjustable. Adjustments are made by
turning the screw using a screwdriver or combination
spanner. The machine is supplied from the factory set to
1 turn open. Turning the screw clockwise will reduce the
oil flow and turning the screw anti-clockwise will increase
the oil flow.
CAUTION! Max. 1 1/2 turns.
Cooling system
To keep the working temperature as low as possible the
machine is equipped with a cooling system.
The cooling system consists of:
1 Air intake on the starter.
2 Air guide plate.
3 Fins on the flywheel.
4 Cooling fins on the cylinder.
5 Cylinder cover (directs cold air over the cylinder).
Clean the cooling system with a brush once a week, more
often in demanding conditions. A dirty or blocked cooling
system results in the machine overheating which causes
damage to the piston and cylinder.
!
WARNING! The engine must be stopped
when making adjustments.
