English – 39
TECHNICAL DATA
Recommended original and replacement bar and chain combinations
Following is a list of recommended cutting equipment for the Husqvarna chain saw models 339XP. The combinations of
power head, bar and chain have been tested and found to be in accordance with the kickback and vibration requirements
of ANSI B175.1–2000.
The guide bar nose radius is determined by either the maximum number of teeth in the nose sprocket or the
corresponding maximum nose radius of a hard nose.
The following list is the chain saw manufacturers recommendations. There may be other combinations available, which
will also achieve kickback reduction.
As we are listing the maximum guide bar nose radius, you may use a guide bar with smaller nose radius than in our list.
For guide bars of the same length, all sprocket-nose guide bars of the same pitch and having the same number of
sprocket teeth may be considered to have equivalent kickback energy. A hard nose bar having the same length and nose
radius as a sprocket-nose bar may be considered to have equivalent or less kickback energy than the sprocket-nose bar.
Low kickback saw chain is a chain which has only met the kickback performance requirements of ANSI B 175.1 safety
requirements for gasoline powered chain saws when tested on the representative sample of chain saws below 3.8 cu.
in. specified in ANSI 175.1. We recommend that you as a replacement use the listed chains or "Low kickback saw chains"
which are available at your dealer.
Bar and chain combinations
Saw chain filing and file gauges
Bar Chain
Length, inch Pitch, inch Gauge, inch Max. nose radius Type Drive link count
13 0,325 0,050 10T Husqvarna H30 56
15 0,325 0,050 10T Husqvarna H30 64
16 0,325 0,050 10T Husqvarna H30 66
18 0,325 0,050 10T Husqvarna H30 72
