English – 5
WHA T IS WHA T?
What is what on the brush cutter? (355RX)
29
30
31
35
34
12
2
3
4 5
7
8
6
10
15
9
11
13
24
21
33
19
18
17
16
20
25
27
26
23
24
28
1
23
32
22
22
14
1 Locking nut
2 Bevel gear
3 Grease filler cap, bevel gear
4 Shaft
5 Handle adjustment
6 Support eyes for harness
7 Fuel tank
8 Cylinder cover
9 Spark plug cap and spark plug
10 Starter handle
11 Air filter cover
12 Handlebar
13 Air purge
14 Decompression valve
15 Choke control
16 Stop switch
17 Start throttle button
18 Throttle lockout
19 Adjusting the throttle wire
20 Throttle control
21 Trimmer head
22 Metal cup
23 Drive disc
24 Cutting attachment guard
25 Locking screw
26 Support cup
27 Support flange
28 Grass blade
29 Transport guard
30 Allen key
31 Carburettor screwdriver
32 Locking pin
33 Socket spanner
34 Operator ′ s manual
35 Harness
