Husqvarna AUTOMOWER 105 User Manual

1. Mark the wires to simplify reconnecting. The
charging station’s connections are marked
R, L and GUIDE.
2. Disconnect all connected wires and the
power supply.
3. Connect all the wires and the power supply
if there is no longer a risk of thunder. It is
important that each wire is connected to the
right place.
1285 - 004 - 16.04.2020 Safety - 13

Husqvarna AUTOMOWER 105 Specifications

General

Cutting Width	17 cm
Cutting Height	20-50 mm
Area Capacity	600 m²
Battery Type	Li-ion
Typical Charging Time	50 min
Typical Mowing Time on One Charge	70 min
Weight	6.7 kg
Maximum Slope	25 %
Battery Capacity	2.1 Ah
Battery Voltage	18 V
Weather Resistance	Yes
Boundary Wire Required	Yes
Smart Connectivity	No
Blade Type	Pivoting Razor Blades
