Husqvarna AUTOMOWER 230 ACX User Manual

English - 31
3. INSTALLATION
3. Place the cable ends in the connector:
• Open the connector.
• Place the wire in the connector grip.
4. Press the connector together using a pair of
pliers. Press until you hear a click.
5. Cut off any surplus boundary wire. Cut 1 - 2 cm
above respective connectors.
6. Press the connector onto the contact pin,
marked A, on the charging station.
IMPORTANT INFORMATION
The right hand connector should be
connected on the right hand contact pin on
the charging station and vice versa.
3012-284
3012-264
3012-265
3012-507

Husqvarna AUTOMOWER 230 ACX Specifications

General

Cutting Width	22 cm
Cutting Height (min-max)	20-60 mm
Battery Type	NiMH
Area Capacity	3000 m²
Maximum Incline	35%
Power Consumption During Cutting	30 W
Cutting System	3 pivoting razor blades
Alarm	Yes
PIN Code	Yes
Lift Sensor	Yes
Tilt Sensor	Yes
Typical Mowing Time on One Charge	60 minutes
Typical Charging Time	60-80 minutes
