10 - English
2. PRESENTATION
2. Presentation
This chapter contains information you should be aware
of when planning the installation.
An installation of Husqvarna Automower™ includes
four main components:
Automower, an automatic lawn mower that mows the
lawn by moving in essentially an irregular pattern.
The mower is powered by a maintenance-free
battery.
Charging station, where your Automower returns
when the charge level in the battery becomes too low.
The charging station has three functions:
• To send control signals along the boundary wire.
• To send out signals so Automower finds the
charging station.
• To charge Automower battery.
Transformer, which is connected between the
charging station and a 230V wall socket. The
transformer is connected to the wall socket via an
integrated power cord and to the charging station via
a 20 m long low voltage cable. The low voltage cable
must not be extended.
Wire, laid in a loop around Automower’s working
area. The boundary wire is laid around the edges of
the lawn and around objects and plants that the
mower must not run into. The wire is also used for
any guide wires.
The wire supplied with the installation is 400 m long
(250 m for 220 AC). If this is not sufficient more wire
can be purchased, with a connector, and spliced onto
the existing wire.
3012-691
3012-509
3012-220
3012-221
