Husqvarna AUTOMOWER 230 ACX User Manual

English - 67
7. GARDEN EXAMPLE
This example only applies to 230 ACX.
Area: 3000 m
2
. Two guide wires are
recommended.
Timer: Operating time of 24 hours per day.
Exit angles: One sector 90° - 270°.
Follow loop out: Area 1; Direction Guide 1,
Distance 40 m and Proportion 20 %. Area 2;
Direction Guide 2, Distance 30 m and
Proportion 40 %.
Search method: Irregular, Follow guide wire
in and Follow boundary wire in.
Delay: Guide 1 2 minutes, Guide 2 2 minutes
and boundary wire 11 minutes.
Corridor width: Guide 1 6, Guide 2 6 and
boundary wire 6.
Proposals for installation and settings
3012-687

Husqvarna AUTOMOWER 230 ACX Specifications

General

Cutting Width	22 cm
Cutting Height (min-max)	20-60 mm
Battery Type	NiMH
Area Capacity	3000 m²
Maximum Incline	35%
Power Consumption During Cutting	30 W
Cutting System	3 pivoting razor blades
Alarm	Yes
PIN Code	Yes
Lift Sensor	Yes
Tilt Sensor	Yes
Typical Mowing Time on One Charge	60 minutes
Typical Charging Time	60-80 minutes
