English – 19
3 Specications
3.1 Technical data PW450 and PW 460
Value Unit PW450 PW460
Max pressure bar 150 160
Voltage V 230 230
Frequency Hz 50 50
Rated current A 12.6 14.5
Power consumption kW 2.9 3.3
Motor speed min
-1
2800 2800
Flow rate, HP l/min 8.4 8.8
Pump pressure bar 126 ±9 135 ±9
Nozzle pressur bar 105 ±9 114 ±9
Standby pressure bar 135 ±15 140 ±10
Retaining time min 5 5
Oil contents ml 80 80
Oil type - BP Bartran HV68 BP Bartran HV68
Max inlet water temperature °C 60 60
Max inlet water pressure bar 10 10
High pressure hose length m 13 15
Suction height m 0.5 0.5
Supply cable length m 5 5
Insulation class (Motor) - F F
Ingress protection class - IPX5 IPX5
Specications
