This operator’s manual describes the Husqvarna
Zero Turn Rider. The rider is fitted with a Kohler or
Kawasaki four-stroke overhead valve engine.
Transmission from the engine is made via belt-driven
hydraulic pumps. Using the left and right steering
controls, the flow is regulated and thereby the
direction and speed.
Control Locations
1
2
3
4
5
6
8
9
10
12
7
11
13
1. Motion control levers
2. Tracking knob
3. Parking brake
4. Fuel tank cap - left
5. Fuel tank cap - right
6. Fuses
7. Hour meter
8. Ignition switch
9. Choke control
10. Throttle control
11. Blade switch
11. Seat adjustment lever
12. Deck lift
13. Deck release
