Husqvarna Rider 11 User Manual

English – 21
WARNING!
No service procedures must be conducted on the engine or cutting unit unless:
• The engine is switched off.
• The ignition key is removed.
• The ignition cable is removed from the plug.
• The parking brake is applied.
• The cutting unit is disengaged.
Maintenance
5025
100
Page
Maintenance interval
in hours
Daily
mainte-
nance
before start
Maintenance schedule
The following is a list of the maintenance which should be conducted on the machine. For the items which
are not described in these instructions go to an authorised service workshop.
● = Described in these instructions.
❍ = Not described in these instructions.
1)
First change after 5 hours. Replace after every 25 hours with heavy loads or high temperatures.
2)
During dusty conditions cleaning
and replacement should be more frequent.
3)
For daily use of the machine lubrication should be conducted twice a week.
4)
Conducted
by authorised service workshop.
Check the engine’s oil level 37 ●
Check the engine’s cooling air inlet 30 ●
Check the fuel pump’s air filter 28 ●
Check the steering wires 24 ●
Check the brakes 25 ●
Check the battery 28 ●
Check the safety system 29 ●
Check screws and nuts – ❍
Check for fuel and oil leakage – ❍
Clean around the silencer – ❍
Change the engine oil
1)
37 ●
1)
●
1)
Replace the air filter’s prefilter
2)
27 ●
Check the cutting unit 31 ●
Check the tyre pressures (60 kPa/8,5 PSI) 30 ●
Lubricating the belt adjuster
3)
38 ●
Lubricate joints and shafts
3)
38 ●
Adjust the brakes – Rider 11 and Rider 11 Bio 25 ●
Check the V-belts – ❍
Check the transmission’s cooling flanges – – ❍
Rider 13 and Rider 13 Bio
Check the transmission’s oil level – Rider 13 and 38 ●
Rider 13 Bio
Adjust the brakes – Rider 13 and Rider 13 Bio 25 ●
Check and adjust the throttle wire 26 ●
Clean the cooling flanges on the engine and – ❍
transmission
2,4)
Replace the air filter’s pre-filter and paper filter
2)
27 ●
Replace the fuel filter 26 ●
Replace the plug 28 ●
Check the valve clearance – ❍
MAINTENANCE
