Husqvarna TF 544 User Manual

English
– 7
ST AR TING AND ST
OPPING
Bef ore starting
• Check the engine oil level and top up if necessary.
Illustr
ation: 2 • 1
• Check the oil level of the gear box, and top up if
necessar
y. Illustration: 2 • 2
• Check the fuel level. Fill if necessary. Illustration: 2 • 3
- Fuel: Diesel fuel
• Oiling the air filter cup. Illustration: 2 • 4
Star t the machine.
• Put the gear shift lever in the ”N” position (neutral).
Illustr
ation: 2 • 5
• Throttle control Illustration: 2 • 6
- Push the throttle control to full throttle position.
• Open the fuel tap. Illustration: 2 • 7
• Start the engine Illustration: 2 • 8
- Press down the decompression lever and hold by hand.
- Grip the starter handle, slowly pull out the cord with your
hand until y
ou feel some resistance (the starter pawls grip),
then return slowly.
- Repeat the procedure three times.
- Press down and release the decompression lever.
- Quickly and powerfully pull the cord. Use two hands if
necessar
y.
Use
Forwar ds
Illustration: 3 • 1
• Use the shifting lever to control the drive speed.
Slow
Fast
• Press down the trigger lock on the handle (A) and push
the clutch le
ver in towards the handle (B).
• The cultivator starts to rotate when you push the clutch
le
ver down towards the handle and stops rotating when
you release the clutch lever.
Reverse
Illustration: 3 • 2
• Put the gear shift lever in the ”N” position (neutral).
• Slide the control to ”R” position.
• Press down the trigger lock on the handle (A) and push
the clutch le
ver in towards the handle (B).
Stopping
• Release the clutch lever. Illustration: 4 • 1
• Put the gear shift lever in the ”N” position (neutral).
Illustr
ation: 4 • 2
• Reduce the throttle and stop the engine. Illustration: 4 • 3
• Close the fuel tap. Illustration: 4 • 4
Moving the machine
Illustration: 5 • 1
• The engine must be switched off before moving. See
instructions under section Stopping.
• Change the tines to wheels when transporting.
(Figure A)
• Lift the drag bar from the ground using the handlebar and
then advance forwards. (Figure B)
!
WARNING! Never twist the starter cord
around your hand.
!
WARNING! Keep unauthorised persons at a
distance. Children, animals, onlookers and
helpers should be kept outside the safety
zone of 20 m. Stop the machine immediately
if anyone approaches.
IMPORTANT! The cultivator starts to rotate when you push
the clutch lever down towards the handle and stops rotating
when you release the clutch lever. It is important to release
the clutch lever before using reverse.
!
WARNING! The use of reverse is dangerous!
Ensure that there are no obstacles behind
you and reduce the engine revs before
engaging the clutch.
STOP
