15
TRACTOR - - MODEL NO. YTH184T (96041030600), PRODUCT NO. 960 41 03-06
MOWER DECK
44
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
1 584 92 75-01 Mower Deck Assembly, 42"
6 532 19 51-86 Arm Susp. Rear
8 532 19 30-03 Bolt/Washer Asm 7/16-20
11 532 13 89-71 Blade Mower 42”
13 532 19 28-72 Shaft As sem bly, Mandrel
14 532 18 72-81 Housing, Mandrel
15 532 11 04-85 Bearing, Ball, Mandrel
19 532 19 65-39 Bolt, Shoulder
20 532 15 97-70 Baffle, Vortex
21 873 68 05-00 Nut
23 532 19 25-57 Bracket, Deflector Mower 42"
24 532 10 53-04 Cap, Sleeve 80 x 112 Blk Mower
25 532 19 70-26 Spring, Torsion, Deflector
26 532 11 04-52 Nut, Push Phos & Oil
27 532 40 30-04 Shield, Deflector 42" Blk
29 532 13 14-91 Rod, Hinge 42" 6 75 W/G
30 532 17 39-84 Screw Thdrol
31 532 18 76-90 Washer, Spacer Mower Vented
32 532 15 35-35 Pulley, Mandrel
33 532 40 02-34 Nut, Toplock
34 872 11 06-12 Bolt Carr SH 3/8-16 x 1-1/2 Gr. 5
36 532 19 73-79 Pulley, Idler, Flat
40 873 90 06-00 Nut Lock 3/8-16
55 532 43 71-10 Arm, Idler
56 532 19 90-92 Spacer, Retainer
57 817 00 06-16 Screw 3/8-16 x 1
59 532 14 10-43 Guard TUV Idler
62 872 11 06-16 Bolt Rdhd Sqnk 3/8-16 unc x 2
68 532 14 49-59 V-Belt, 42" Mower
69 872 14 05-05 Bolt, Carriage 5/16-18 x 5/8
116 532 12 48-42 Bolt, Shoulder
117 532 18 86-06 Wheel, Gauge
119 819 12 14-14 Washer 3/8 x 7/8 x 14 Ga.
145 532 19 31-97 Pulley Idler Primary
188 532 19 51-61 Stud Fastner w/D Anti-Rotation
189 873 90 05-00 Nut Lock Hex Flange 5/16-18
190 532 19 72-51 Spring Mower Drive
241 532 15 29-27 Screw TT #10-32.5. 3/8
242 532 41 55-98 Port Washout
- - 532 19 28-70 Mandrel Assembly (Includes housing
(Key #14), shaft assembly(Key #13),
and bearing only (Key #15) - pulley/
nut/washer and blade bolt/washers
not included)
- - 583 93 50-02 Replacement Mower, Complete (Std.
deck Order separately gauge wheel
components Key Nos. 116-119)
To Next Page
