Husqvarna YTH184T User Manual

7
TRACTOR - - MODEL NO. YTH184T (96041030600), PRODUCT NO. 960 41 03-06
CHASSIS AND ENCLOSURES
39
39
KEY PART
NO. NO. DESCRIPTION
3 532 44 44-81 Applique
5 532 43 74-84 Dash
14 532 44 11-77 Hood
15 532 43 97-33 Lens LH
18 532 43 77-62 Grille
25 532 44 33-85 Lens RH
34 580 91 08-01 Plate Engine
36 817 06 05-12 Screw 5/16-18 x 3/4
37 532 44 12-08 Fender
52 873 68 05-00 Nut Crown Lock 5/16-18
58 532 41 22-81 Drawbar Upper
68 817 49 05-08 Screw 5/16-18 x 1/2
125 581 68 48-01 Clip Fuel Line
130 532 41 63-58 Screw #10 x 0.750 BOS Thread
137 532 40 75-90 Bumper Hood/Dash
146 581 85 79-01 Bolt
150 532 43 97-31 Duct Air
151 532 43 66-70 Bracket Pivot
152 532 43 98-70 Shield Browning
159 817 00 06-12 Screw Hexwsh Thdr 3/8-16 x 3/4
161 532 43 99-29 Console Fuel Window
162 532 14 24-32 Screw Hex Wsh Hi-Lo 1/4 x 1/2
165 532 19 68-26 Bracket Support Tank
175 532 19 63-04 Crossmember
176 532 40 07-76 Screw 10-24 x 5/8 Rnd Qdrx
177 532 19 52-27 Bushing Steering
178 532 19 97-82 Cargo Asm. Net
180 532 41 50-64 Chassis
182 532 40 68-59 Dash Lower
183 874 52 05-20 Bolt Hex 5/16-18 x 1-1/4
189 817 00 05-12 Screw 5/16-18 x 3/4
191 532 43 74-55 Insert Reflective RH
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
KEY PART
NO. NO. DESCRIPTION
194 873 90 05-00 Nut Lock Hex Flange 5/16-18
195 532 40 41-37 Plug 12v Adapter
196 532 43 97-16 Console Asm. Deck Lift
199 532 19 82-59 Plate Deck Lift
202 532 43 97-28 Vent Side Hood RH
203 532 43 97-27 Vent Side Hood LH
204 532 44 06-65 Vent Hood Top
205 532 43 97-30 Skirt Hood Side RH
206 532 43 97-29 Skirt Hood Side LH
207 532 43 97-34 Bezel RH
208 532 43 97-35 Bezel LH
213 874 76 05-12 Bolt Hex Hd 5/16-18 unc x 3/4
214 532 19 91-45 Clip Retainer
217 532 40 91-67 Rod Pivot
218 532 19 63-95 Hood Stop
221 532 19 89-09 Reflector LH
228 532 19 51-61 Stud Fastner
229 532 44 14-63 Lid Ext. Fill
234 532 40 47-42 Bumper Hood
235 532 40 61-29 Spacer Fender
236 873 93 05-00 Nut Center Lock 5/16-18 unc
297 532 43 74-56 Insert Reflective LH
306 873 90 06-00 Nut Lock
335 532 44 82-04 Cover Dash RH
336 532 44 53-09 Cover Dash LH
350 532 44 51-43 Clip X-mas Tree
- - 532 40 09-44 Bumper Kit
