CONTROLS
1. Steering / park brake controls
2. Tracking bolt, left
3. Deck lift
4. Fuses
5. Bypass Linkages
6. Fuel shut off valve
7. Fuel tank
8. Throttle control
9. Service meter
10. Ignition switch
11. Blade switch
12. Seat Adjustment Lever
This operator manual describes the Husqvarna
Zero Turn Rider. The rider is tted with a four-
stroke overhead valve engine.
Transmission from the engine is made via
belt-driven hydraulic pumps. Using the left and
right steering controls, the ow is regulated and
thereby the direction and speed.
1
2
10
11
12
3
4
6
7
8
9
5
