REV K 4-4 605596
When threading the fuel cap onto the filler neck, tighten the
cap until it begins to click, then, continue to turn it until at
least three clicks are heard.
IMPORTANT: Do not overfill the fuel tank. The fuel tank
should be filled
no higher than the bottom of the fill neck. The
fuel system is designed to leave room for the fuel to expand
with fuel temperature changes. Figure 4-6
Use regular unleaded gasoline with an octane rating of 87
or higher. Maximum of 10% ethanol (E10) in fuel. Fuels with
greater than 10% ethanol (such as E15, E20 and E85) voids
warranty. Fuels with greater than 10% ethanol are not
approved for use and such illegal use could cause equipment
failure and pose a fire hazard.
Refer to the Engine Owner’s Manual for additional fuel
specification requirements.
Fuel Shut-off Valve
This mower is equipped with a fuel shut-off valve, located
behind the seat platform. When closed the fuel valve
prevents fuel flow to the engine.
Figure 4-7
Fuel Evaporation System Filter
Hustler
®
FasTrak
®
mowers have a fuel evaporation system
filter. This filter must be checked and replaced every 300
hours or annually whichever comes first.
Figure 4-8
A. Fuel cap
Figure 4-5
Overfilling the fuel tank may cause the following:
• Engine damage
• Fire hazard!
A. Filler neck B. Fuel tank
Figure 4-6
A
WARNING
A
Fill to the bottom of the filler neck
Maximum
Do Not
Overfill
B
Valve shown in open position
A. Fuel shut-off valve
Figure 4-7
A. Fuel evaporation system filter
Figure 4-8
A
A
