REV D 3-8 114510
Anti-scalp Wheels
Anti-scalp wheels are standard on some TrimStar
®
mowers. These anti-scalp wheels are designed to minimize
scalping when mowing on rough, uneven terrain.
After setting the cutting height, adjust the anti-scalp
wheels so they extend below the deck but do not contact the
ground. They should always be at least 1/4” to 3/4” (6.35mm
to 19.05mm) below the deck. With the unit sitting on a flat
level surface, the wheel position can be adjusted up or down
as needed from 3/4” to 1-3/4” (19.05 mm to 44.45 mm) below
the blade surface. Move the wheels up or down, in 1/2”
(12.70 mm) increments, using the different axle mount holes
in the wheel mount bracket. Figure 3-14
When adjusting the rear anti-scalp wheels, the wheel
should be in the same axle mount hole as the front anti-scalp
wheels.
Stand-up Sulkies
Hustler
®
Turf Equipment does not warrant or accept liability
for the use of any attachments not manufactured by Hustler
®
Turf Equipment, including the use of stand-up sulkies.
All manufacturer’s safety instructions issued with any
attachments including stand-up sulkies must be followed.
A. Adjusting hole B. Anti-scalp wheel
Figure 3-14
A
B
