Power Supply – Dimensions and Weight
Weight of power supply
without torch
124 lb
(56.2 kg)
26.4 in
(671 mm)
16.8 in
(427 mm)
25.8 in
(655 mm)
Duty Cycle
Duty cycle is the percentage of time, during a 10 minute period, that the power supply can cut continuously. The
diagram below depicts an 80% duty cycle.
Note: Refer to Specifications – Power Supply to determine the duty cycle that corresponds with the input power.
8 minutes
cutting
2 minutes
resting
