INITIALIZING THE INCHING SENSOR
INITIALIZING THE INCHING SENSOR
Start engine after parking the machine on flat floor and blocking wheels.
Release parking brake and keep neutral gear shift.
Adjust the inching sensor linkage so that the regular voltage is supplied to inching sensor when
operating the pedal.
(Regular voltage ; Before pedal operation (1
±0.1V),
After pedal operation (3.5
±0.1V))
Stop the engine and then just KEY ON. (Release parking brake, keep neutral gear)
Connect the AEB STARTER to the T/M controller.
Push AEB STARTER over 3 seconds.
If display shows "
▼IP", Step on the pedal fully.
If display shows "
▲IP", release "OK"
After the successful completion, it displays "OK".
In case of abnormal running, it may display "STOP" with the appropriate error code.
After troubleshooting, start the machine again to repeat above.
Above works are to be done with the parking brake released, so machine's wheels must be
blocked for safety.
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
※
4)
DISPLAY DURING INCHPEDAL CALIBRATION
DISPLAY DURING INCHPEDAL CALIBRATION
5)
Symbol Meaning Remarks
▼IP Push down the pedal slowly until endposition is
reached and hold this position
▲IP Release the pedal slowly until endposition is
reached
IP blink A problem occurred, release the pedal slowly
until endposition is reached
If the expected endposition could not be
reached, release the pedal and try again
OK Finished inchpedal calibration successful
FN and Stop Shift lever not in Neutral position Calibrations is aborted
FS and Stop
Sensor supply voltage AU1 is out of the
specified range
Calibrations is aborted
FO and Stop Output speed is not zero Calibrations is aborted
SL and Stop Sensor voltage below specified range Calibrations is aborted
SU and Stop Sensor voltage below specified range Calibrations is aborted
IL and Stop Sensor position for released pedal out of
specified range
Calibrations is aborted
IU and Stop Sensor position for pressed pedal out of
specified range
Calibrations is aborted
TO and Stop Time-out calibration, pedal not moved after
calibration start
Calibrations is aborted
DL and Stop Angle between pedal positions released and
pressed to small
Calibrations is aborted
DU and Stop Angle between pedal positions released and
pressed to big
Calibrations is aborted
FI and Stop Sensor signal 1 and 2 don't match together Calibrations is aborted
