5-15
With the parking brake released and the direction control in
FORWARD or REVERSE, put your foot on the accelerator
pedal and push down smoothly until the truck is moving at the
desired speed.
To stop the truck, lift your foot from the accelerator pedal and
put it on the brake pedal. Push down on the brake pedal in a
smooth, firm motion until the truck is stopped.
Stop the lift truck as gradually as practical. Hard braking
and wheel sliding are dangerous, incr
ease wear, and can
cause you to loose a load and damage to the lift truck.
Can cause tip-over.
USING THE ACCELERATOR PEDAL
3)
BRAKING PEDAL
4)
INCHING PEDAL
5)
D35AOM131
160D7OM131
50D/60D/70D-7E, 80D-7E
D35AOM132
160D7OM132
50D/60D/70D-7E, 80D-7E
D35AOM133
160D7OM133
50D/60D/70D-7E, 80D-7E
Use the inching pedal and the accelerator pedal in combination
to vary lift and travel speeds independently. The further you
depress the inching pedal, the more the driving clutch slips,
reducing travel motion. With the inching pedal fully depressed,
the brakes fully engage. You operate the inching pedal with
your left foot for precise control of travel speed, while you
operate the accelerator pedal together with the lift control to
vary lift speed.
When slipping the clutch, it can happen heating in the
system and reduced a durability of the compon
ents.
When operating accelerator, avoid frequent use and cut
off the power of the traveling by pressin
g sufficiently the
inching pedal.
