BEACON SWITCH
(OPTION)
6)
ON
OFF
L255OM18
This switch is used to operate work lamps.
Press this switch to turn on work lamps.
5.0 ~ 8.0 ton : Standard
1.5 ~ 4.5 ton, 50DA-7E, 50D-7AE : Option
WORK LAMP SWITCH
(1)
(2)
This switch turn ON the rotary light. (1)
5)
ON
OFF
L255OM16
Manual mode
( Η )
Press the top of the switch fully for the manual mode of the autoshift
function. The operator selects the desired speed and the desired
direction in the manual mode with the gear selector lever.
Automatic 1st mode
( Θ )
Place the switch in the middle position for the autoshift function
changing from
11st
to
3rd
gear shift mode.
Automatic 2nd mode
( Ι )
Press the bottom of the switch fully for the autoshift function
changing from
2nd
to
3rd
gear shift mode.
AA
M
A
A
M
1
2
FULL AUTOMATIC SWITCH
(50D/60D/70D-7E, 80D-7E)
(1)
(2)
(3)
D507CD60
Η
Θ
Ι
77)
CLUTCH CUT OFF SWITCH
(50D/60D/70D-7E, 80D-7E)
This switch is pressed, it will cut off the clutch when brake operates.
Be careful not to use this switch when driving on a slope.
OFF
ON
8)
(1)
ö
73033CD17
Use for parking, or loading machine.
I
If the switch is left ON for a long time, the battery may be
discharged.
5.0~8.0
ton : Standard
1.5~4.5 ton, 50DA-7E, 50D-7AE : Option
HAZARD LAMP SWITCH
(1)
ö
(2)
4)
ON
OFF
L255OM17
