8-2
Specifications & Consumer information
Light Bulb Wattage (W)
Headlights (High/Low) 60/55
Front turn signal 21
Position lights 5
Side repeater light*(Outside mirror) LED
Front fog light 35
Stop and tail light (Rear) 21/5 or LED
Tail light (Rear) 5 or LED
Rear turn signal light 21
Back-up light (Rear) 21
High mounted stop light* 5
License plate light 5
Map lamps 8
Room lamps 8
Luggage room lamp* 10
Item mm (in)
Overall length 3,985 (156.9)
Overall width 1,734 (68.3)
Overall height 1,485 (58.4)
Front tread 1,523 (59.9)*
1
/1,511 (59.5)*
2
Rear tread 1,525 (60.0)*
1
/1,513 (59.6)*
2
Wheelbase 2,570 (101.2)
*
1
: with R14 tire
*
2
: with R16 tire
Item Gasoline 1.2 Gasoline 1.4 Diesel
Displacement
cc (cu. in)
1,197 (73) 1,368 (83.5) 1,396 (85.2)
Bore x Stroke
mm (in.)
71.0 x 75.6
(2.8 x 3.0)
72 x 84
(2.8 x 3.3)
75 x 79
(3.0 x 3.1)
Firing order
1-3-4-2 1-3-4-2 1-3-4-2
No. of cylinders
444
