6
DO-IT-YOURSELF MAINTENANCE
14
FILLING THE WASHER
RESERVOIR
G090A02HR-GAT
The washer fluid reservoir supplies fluid
to the windshield washer system.
A good quality washer fluid should be
used to fill the washer reservoir. The
fluid level should be checked more
frequently during inclement weather or
whenever the washer system is in more
frequent use.
The capacity of the washer reservoir is
2.0 liters.
HHR5016
To install the wiper blade
HHR5050
1. Put a new wiper blade onto the wiper
arm and lower the wiper blade at the
level of the wiper arm as shown in the
drawing.
2. Pull up the wiper blade until you hear
an audible "click" to engage in the
end of the wiper arm.
NOTE:
Do not allow the wiper arm to fall
against the windshield.
HHR5051
2. Raise the wiper blade lightly and pull
up it.
HHR5049
To Next Page
