8. SPECIFICATION.
MODEL
HYBC5080AV (TITAN)
ENGINE
Engine type
Single cylinder, 2 stroke, air cooled.
Engine size - cc
50.8
Fuel tank capacity - ml
800
Noise level dB (A)
117
Max speed - rpm
7500
Power - kw
1.80
Start method
Recoil
Fuel type/ratio
Fresh unleaded petrol mixed with Semi-synthetic 2
Stroke oil first use ratio 25:1 - thereafter use ratio of
40:1
Drive type
Centrifugal clutch
MACHINE
Head line length/diameter - mm
3000/2.5
Cutting width mm /length
mm /diameter mm
255mm for cutter blade / 400-450 for cutter
head (Blade 1.6mm/3T
Gross weight - kg
13.68
Dry weight kg
9.68
Fully assembled dimensions L x
W x H - mm
1820 x 750 x 500
Bevel gear - grease type/qty ml
High temperature gear grease/25
