14
4. INSTALLING GUIDE BAR & CHAIN
A standard saw unit package
contains the items as shown below:
1. Power unit
2. Saw chain
3. Guide bar
4. Guide bar cover
5. Sparkplug wrench
6. File
Open the box and install the guide bar and the saw chain on the
power unit as follows.
The saw chain has very sharp edges. Use protective gloves for
safety.
1. Pull the guard towards the front handle to check that the chain
brake is not on.
2. Loosen a nut and remove the chain cover and spacer.
3. Fit the chain to the sprocket and, while tting the saw chain
around the guide bar, mount the guide bar to the power unit.
Adjust the position of chain tensioner nut.
To Next Page
