Hyundai HYC5620 User Manual

Page 9
Rev 2
Make certain that the area in which you’re cutting is free from obstructions. Do not
let the nose of the guide bar contact a log, branch, or any other obstruction which
could be hit while you are operating the saw.
Cut at high engine speeds.
Do not overreach or cut above shoulder height.
Follow manufacturers sharpening and maintenance instructions for saw chain.
Only use replacement bars and chains specified by the manufacturer or the
equivalent.
3. MACHINE PARTS
3.1. All Models.
1
Guide Bar Scabbard
9
Oil Tank Filler Cap
2
Guide Bar
10
Starter Pull Cord
3
Chain
11
Fuel Tank Filler Cap
4
Front Hand Guard and Chain
Brake Lever
12
Engine Switch
5
Front Handle
13
Throttle trigger
6
Air Filter Cover
14
Throttle Tigger Lock-out
7
Air Filter Lock Nut
15
Primer Bulb
8
Choke Knob
16
Chain adjuster
