Hyundai HYMT5080 User Manual

4.6 Adjust the chain tension by turning the tensioner
screw (1) until the tie straps just touch the bottom of the
bar rail.
4.7 Tighten the mounting nut securely with the bar
tip held up. Whilst wearing safety gloves check the
chain for smooth rotation and correct tension whilst
moving with hand.
Pay attention to the correct direction of the saw chain.
It is very important to maintain proper chain tension. Rapid wear of the
guide bar or chain coming off easily can be caused by improper tension
When using a new chain take great care to check adjustment because the
chain will expand when first used.
Page 16

Hyundai HYMT5080 Specifications

General

Engine Type	Single cylinder, 2 strokes, air-cooled engine, 1E43F-B
Engine size - cc	50.8CC
Start method	Recoil
Fuel tank capacity - ml	800ML
Fuel ratio/fuel type	40:1 Semi-Synthetic 2-Stroke oil/unleaded petrol
Noise Level - dB	117
Rated power - kw	1.56kw
Rated speed - rpm	7500 rpm
Cutter head - mm	400-450
Head Line diameter - mm x length - m	2.4 x 4
Cutter blade mm/teeth	1.6mm/3T
Cutting Width - mm/length - mm/ diameter - mm	255mm for cutter blade / 400-450 for cutter head
Chainsaw bar length – inches (mm)	12 (300)
Hedge Trimmer Blade length – inches (mm)	18 (450)
Clutch type	Centrifugal type

Weight and Dimensions

Gross weight - kg	14.50
Dry weight - kg	12.50
Box Dimensions - L x W x H - mm	1070 x 280 x 300
Chainsaw total length – mm	3270 (with extension pole)
Hedge Trimmer total length – mm	3440 (with extension pole)
Brush cutter total length – mm	1860
