Hyundai HYMT5080 User Manual

TABLE of CONTENTS
1. SAFETY
4 – 10
2. SPECIFICATION
11
3. COMPONENT LOCATIONS
12
4. ASSEMBLY
13 – 16
5. FUEL & OIL
17 – 18
6. STARTING/STOPPING& USING MACHINE
19 – 23
7. MAINTENANCE
24 – 28
8. STORING THE MACHINE
28 – 29
9. TROUBLESHOOTING
29
10. DISPOSAL OF MACHINE
30
11. CERTIFICATE OF CONFORMITY
30
12. CONTACT DETAILS
31
Page 3

Hyundai HYMT5080 Specifications

General

Engine Type	Single cylinder, 2 strokes, air-cooled engine, 1E43F-B
Engine size - cc	50.8CC
Start method	Recoil
Fuel tank capacity - ml	800ML
Fuel ratio/fuel type	40:1 Semi-Synthetic 2-Stroke oil/unleaded petrol
Noise Level - dB	117
Rated power - kw	1.56kw
Rated speed - rpm	7500 rpm
Cutter head - mm	400-450
Head Line diameter - mm x length - m	2.4 x 4
Cutter blade mm/teeth	1.6mm/3T
Cutting Width - mm/length - mm/ diameter - mm	255mm for cutter blade / 400-450 for cutter head
Chainsaw bar length – inches (mm)	12 (300)
Hedge Trimmer Blade length – inches (mm)	18 (450)
Clutch type	Centrifugal type

Weight and Dimensions

Gross weight - kg	14.50
Dry weight - kg	12.50
Box Dimensions - L x W x H - mm	1070 x 280 x 300
Chainsaw total length – mm	3270 (with extension pole)
Hedge Trimmer total length – mm	3440 (with extension pole)
Brush cutter total length – mm	1860
