G220102APA
Front fog light bulb replacement
1. Reach your hand into the front
bumper.
2. Remove the socket from the housing
by turning the socket counter clock-
wise until the tabs on the socket align
with the slots on the housing.
3. Remove the bulb by pulling it straight
out.
4. Install a new bulb in the socket.
5. Install the socket in the housing by
aligning the tabs on the socket with
the slots in the housing. Insert the
socket into the housing and turn the
socket clockwise.
G220200APA
Side repeater light bulb replace-
ment (if equipped) Type A
1. Remove the light assembly from the
body of the vehicle by prying the lens
and pulling the assembly out.
2. Disconnect the bulb electrical connec-
tor.
3. Separate the socket and the lens part
by turning the socket counterclock-
wise until the tabs on the socket align
with the slots on the lens part.
4. Remove the bulb by pulling it straight
out.
5. Insert a new bulb in the socket.
6. Reassemble the socket and the lens
part.
7. Connect the bulb electrical connector.
8. Reinstall the light assembly to the
body of the vehicle.
Type B
If the light bulb does not operate, have
the vehicle checked by an authorized
HYUNDAI dealer.
OPA077037OPA077056
TYPE A
OPA071061
TYPE B
954
Maintenance
