Description Fuse rating Protected Component
FUSE
P/TAIL GATE 30A Power Tail Gate Module
IDB 15A IDB Module
4WD 20A 4WD ECM
AMS 10A Battery Sensor
AMS (WIPER) 10A BCM, PCM
WIPER FRT 25A Wiper LO Relay, Front Wiper Motor
B/UP LAMP 10A
A/T - Rear Combination Lamp (IN) LH/RH, Electro Chromic Mirror, Audio, A/V & Navigation
Head Unit
ABS3 7.5A ESC Module
SENSOR5 7.5A PCM
TCU 15A A/T : Transaxle Range Switch
F/PUMP 15A Fuel Pump Relay
ECU 1 15A PCM
ECU 2 10A IDB Module
SENSOR 3 10A Fuel Pump Relay
IGN COIL 20A Condenser, Ignition Coil #1/#2/#3/#4
SENSOR 2 10A Purge Control Solenoid Valve, Variable Intake Solenoid Valve(G4KJ), Oil Control Valve #1/#2
SENSOR 1 15A
Oxygen sensor(#1/#2/#3/#4), PCM, Oxygen Sensor(Down), E/R Fuse & Relay Box (Cooling
Fan Relay)
B/A HORN 10A Burgl Aralarm Horn Relay
To Next Page
