Maintenance
707
Engine compartment main fuse panel
Description Fuse rating Protected component
MULTI
FUSE
MDPS 80A EPS Control Module
BLOWER 40A Engine Room Fuse & Relay Box (Blower Relay)
EcoShift dual clutch
transmission 1 (GDI)
40A TCM
RR HTD 40A Engine Room Fuse & Relay Box (Rear Defogger Relay)
ALT
GDI 125A
Engine Room Fuse & Relay Box (Multi Fuse - EcoShift dual clutch transmission 1,
MDPS, RR HTD, BLOWER), Alternator
T-GDI 150A
ABS 2 30A Multipurpose Check Connector, ESC Module
B+ 2 50A
Smart Junction Box (Power Window Relay, IPS Control Module (ARISU LT),
Fuse - SAFETY POWER WINDOW, AMP)
B+ 1 50A
Leak Current Autocut Device (Room Lamp Relay, Leak Current Autocut Switch,
Fuse - INTERIOR LAMP, MULTIMEDIA, MEMORY ), Fuse - S/HEATER
FUSE
C/FAN
GDI 40A Engine Room Fuse & Relay Box (Cooling Fan (High) Relay, Cooling Fan (Low) Relay)
T-GDI 60A Engine Room Fuse & Relay Box (Cooling Fan (High) Relay)
A/CON 10A Engine Room Fuse & Relay Box (A/CON Relay)
FOG LP FRT 10A Engine Room Fuse & Relay Box (Fog Lamp Relay)
HORN 15A Engine Room Fuse & Relay Box (Burglar Alarm Horn Relay, Horn Relay)
SUNROOF 20A Panorama Sunroof Motor
IG 2 40A
Ignition Switch, PDM Relay Box (IG 2 Relay),
Engine Room Fuse & Relay Box (Start Relay)
IG 1 40A Ignition Switch, PDM Relay Box (IG 1 Relay, ACC Relay)
