©Copyright LOTRONIC 2017 DJM160BT-MKII 5
BLUETOOTH PAIRING PROCEDURE
1. Press the Mode button (1) on the MP3 player control part
2. Select the BLUETOOTH mode
3. Start the searching procedure on your device
4. Select BT in the list of found devices and connect the mixer to your device
SPECIFICATIONS
AUDIO INPUTS
Mic input ................................................................................... 20mV, unbalanced
Line inputs 1 and 2 ....................................................................... 0.8V, unbalanced
AUDIO OUTPUTS
Main Out ..................................................................................... max. 5V (LINE IN)
Headphones ............................................................... typically 300mW @ 1% THD
GENERAL
Signal-to-noise ratio (S/N) ............................................................................ > 70dB (Line in)
Crosstalk ....................................................................................................... > 50dB (Line in)
Distortion (THD) ........................................................................................................< 0.05%
Frequency response ......................................................................................... 20Hz - 20kHz
Power supply ........................................................ 230V ~, 50Hz via supplied 12Vac adaptor
Power consumption ............................................................................................... max. 4 W
Dimensions (H x W x D) ............................................................... approx. 35 x 250 x 140mm
Electric products must not be put into household waste. Please bring them to a recycling centre. Ask your local authorities
or your dealer about the way to proceed.
