Select your rack model to view its specifications.
Model 0550 and 9406-830 rack
Rack specifications provide detailed information for your rack, including dimensions, electrical, power,
temperature, environment, and service clearances.
Table 30. Dimensions
Maximum
configuration weight
Width Depth Height EIA units
644 kg (1417 lb) 650 mm (25.5 in.) 1020 mm (40.0 in. ) 1800 mm (71.0 in. ) 36
The 1.8 meter rack has 10 EIA units of space remaining. This space will be filled with a 5 EIA filler panel, a 3 EIA
filler panel, and two of the 1 EIA filler panels. Because the rack does not have power distribution, the model
9406-830 rack requires a power cord of sufficient length to reach the receptacle. The power cord for model 9406-830
rack must be used to determine the appropriate receptacle.
Figure 1. 0550 rack
Figure 2. 0550 rack configuration
18 Site and hardware planning
