Denition of an alteration
An alteration is any change to an IBM machine that deviates from IBM physical, mechanical, electrical, or
electronic design (including microcode) whether extra devices or parts are used. An alteration is also an
interconnection at some place other than an IBM dened interface. See the Multiple Supplier Systems
Bulletin for more detail.
For an altered machine, service is conned to the unaltered portions of the IBM machine.
After inspection, IBM will continue to make Warranty Service or Maintenance available, as appropriate,
for the unaltered portion of an IBM machine.
IBM will not maintain the altered portion of an IBM machine under either an IBM Agreement or on an
Hourly Service basis.
If you have more questions about power cord modication, contact an IBM service representative.
Uninterruptible power supply
Uninterruptible power supplies are available to meet the power protection needs of IBM servers. The
uninterruptible power supply (UPS) is the IBM type 9910.
The IBM 9910 uninterruptible power supply solutions are compatible with the power requirements for
Power Systems servers and pass IBM testing procedures. The uninterruptible power supplies are
intended to provide a single source for purchase and protection of IBM servers. All 9910 uninterruptible
power supplies include a premium warranty package that is designed to enhance the potential for return
on investment over the uninterruptible power supplies available on the market today.
Type 9910 uninterruptible power supply solutions are available from Eaton.
For more information about power warning and system shutdown events, or on making changes to the
default conguration options such as system shutdown time when a power failure is detected, see:
• AIX
®
: rc.powerfail Command
• IBM i: Uninterruptible power supply delay time system value
Feature code ECCF (Part number 00FV631) - System Port Converter Cable for UPS
The ECCF is a converter cable that allows for communications from a UPS relay interface card to a service
processor USB port. The server has two service processor USB 2.0 ports on the native I/O daughter card
that are labeled 1 and 2. Either of these ports (1 or 2) can be used for the ECCF. Only one ECCF is allowed
per server. The connectors on the ECCF include a male USB and a female 9-pin D-shell connector. The
cable length is 1650 mm (65 inches).
The cable can be connected to either USB port 1 or USB port 2 at any time. It is not necessary to IPL the
server for the server to recognize the cable. The cable contains active electronics that tell the service
processor that a UPS is attached. The UPS can provide status information (such as UPS on, UPS utility fail,
UPS battery low, and UPS bypass) over the cable to the physical hypervisor for broadcast to all partitions.
Notes:
1. The two service processor USB 2.0 ports that are labeled 1 and 2 correspond to location codes Un-P1-
C1-T3 and Un-P1-C1-T4. For more information about location codes, see Part locations and location
codes.
2. Feature code (FC) ECCF is available for select systems.
3. The pin layout for the 9-pin D-shell connector is as follows:
• 5 - Signal ground
• 6 - UPS bypass
• 7 - UPS battery low
• 8 - UPS on
• 9 - UPS utility fail
96
Power Systems: Site and hardware planning
