IBM IntelliStation M Pro Technical Information Manual

Appendix A. Connector Pin Assignments
Ethernet Connector
2
1
8
7
Figure 15. Ethernet Connector
The external interface for the Ethernet port is an 8-pin, RJ-45 connector.
Table 49. Pin Assignments for the Ethernet Connector
Pin Signal Name I/O
1 TxD+ O
2 TxD− O
3 RxD+ I
4 Ground NA
5 Ground NA
6 RxD− I
7 Ground NA
8 Ground NA
52 Technical Information Manual
