Ice i20NB User Manual

13
ICE i20NB / i20NBT / i20NBT-OB / i24BT
OPERATOR MANUAL
TECHNICAL SPECIFICATIONS
MODEL
i20NB
Brush Assist
i20NBT
W/ Drive
i20NBT-OB
Orbital head
i24BT
Dual disk
DIMENSIONS L 55.7 in / 1,415 mm 53.5 in / 1,360 mm 52.2 in / 1,325 mm
DIMENSIONS W 22 in / 560 mm 22 in / 560 mm 25.6 in / 650 mm
DIMENSIONS H 44.9 in / 1,140 mm 44.9 in / 1,140 mm 44.9 in / 1,140 mm
WEIGHT 210 lbs / 95 Kg 230 lbs / 105 Kg
WEIGHT with BATTERIES 410 lbs /185 Kg 440 lbs / 200 Kg
RECOVERY TANK
CAPACITY
17.2 Gal / 65 L
SOLUTION TANK
CAPACITY
15.9 Gal / 60 L
SQUEEGEE WIDTH 30 in / 762 mm
CLEANING PATH WIDTH 20 in / 500 mm (Disk)
500 mm / 20 in
(20 in x 14 in Pad)
24 in / 600mm
PRODUCTIVITY RATE
19,375 ft
2
/
1,800 m
2
h
23,680 ft
2
/ 2,200 m
2
h
28,000 ft
2
/
2,600m
2
h
DRIVE SYSTEM Brush Assisted Transaxle, 0.27 hp / 0.2KW
TRAVEL SPEED,
MAXIMUM
N/A
246 ft / Min
75 m / Min
MINIMUM AISLE TURN 63 in / 1,600 mm
PAD/BRUSH PRESSURE
65 lbs / 30 Kg Min
100 lbs / 45 Kg Max
SOLUTION FLOW RATE
0 ~ 0.37 Gal / Min
0 ~ 1,400 ml / Min
BRUSH MOTOR
0.75hp / 0.55KW
220 RPM
0.75hp / 0.55KW
2,200RPM
0.9hp / 0.68KW
2,000RPM
VIBRATIONS @
CONTROLS
N/A
< 2.5 m / s
2
< 8.2 ft / s
2
N/A
VACUUM MOTOR 0.7hp / 0.5KW
WATER LIFT - AIR FLOW 45 in / 1,143 mm
BATTERIES 2- 12, 130AH @ 20 hr
RUN TIME PER CHARGE 3.5 Hours 3 Hours
VOLTAGE DC 24V
DECIBEL RATE AT
OPERATOR'S EAR,
INDOORS
68dB(A) <70dB(A) 68dB(A)
GRADE LEVEL, MAX 5% (3°)
